Futaba Reciever R3001SB 2,4 GHz, T-FHSS 18 channel

Envelop

€ 69.90 *Prijzen zijn inclusief btw

Fabrikant: FUTABA
Artikelcode: P-R3001SB

0 ster(ren) met 0 review(s) Schrijf een review

Op voorraad

Aantal

Technische Daten

Categorie 18-kanaals ontvanger

Gewicht 4.2 g

Voedingsspanning 4.8 - 8.4 V

Breedte 21.1 mm

Fabrikantnr. P-R3001SB

Frequentie 2,4 GHz

Hoogte 5.3 mm

Lengte 41.8 mm

Max. voedingsspanning 8.4 V

Min. voedingsspanning 4.8 V

Futaba R3001SB T-FHSS SBus Full Range Drone Receiver

This is the Futaba 2.4GHz R3001SB 2-Port T-FHSS S.Bus Telemetry Receiver.

The Futaba R3001SB is a dedicated S.Bus receiver with built-in T-FHSS telemetry making it especially suited to use on multirotor/drone models.

The single S.BUS/S.BUS2 wire can connect to most of the popular flight controllers reducing the amount of connections needed for a lighter, simpler, more reliable and cleaner installation.

Stripped back to essentials the R3001SB weighs in at only 4.2g thanks to its compact dimensions and heat shrink case.

Don't let the compact size fool you as the R3001SB is capable of the same full range you as any other T-FHSS receiver thanks to the dual diversity antennas.

The R3001SB isn't limited to just drones as the compact form factor lends itself to many other models

(such as helicopter and aircraft) where a compact and neat installation is required taking advantage of Fuaba's S.BUS technology.

• Secure link using Futaba's T-FHSS system

• Telemetry capability

• Lightweight (4.2g) and compact design

• Easy bind using bind button

• Easy connection to popular control boards

FEATURES

T-FHSS 2.4GHz receiver for aircraft

Standard PWM (CH3)/S.Bus port and an S.Bus-2 port for telemetry

sensors and other devices requiring S.Bus setup such as specific

gyros and servos

Channel Mode Settings; Mode A Mode B

3/S.Bus CH3 S.Bus

Dual antenna diversity

High voltage

Battery failsafe

INCLUDES

R3001SB 2-Port T-FHSS S.Bus Telemetry Receiver

Instruction Sheet

SPECIFICATIONS

Dimensions: 0.83 x 1.65 x 0.21" (21.1 x 41.8 x 5.3mm)

Weight: 0.15oz (4.2g)

Power Requirement: 4.8-7.4V

Battery FS Voltage: Sets from transmitter

COMMENTS

S.Bus/S.Bus2 Port: The R3001SB can be used with up to 18 channels.

However, it differs according to the transmitter. An unused channel

is a neutral signal. The F/S setting channel at F/S/ is F/S/

position. Another, it is a hold signal.
